Designed to last, Geberit Delta frames incorporate tried and tested materials which will serve you for years to come. Installed 60 million times over the past 50 years, Geberit concealed cisterns and flush plates represent the ultimate tried and tested solution .
Dual flush with volume adjustment options to help save water.
Leakproof due to one piece blow moulded cistern.
Compatible with all Geberit flush buttons and Geberit Delta Flush Plates.
Every blow moulded cistern is factory-made leak tested, therefore there are no unnecessary sealings or leakage of the cistern for maximum operational reliability.
25 Year spare parts Guarantee.
Product Features
- Very Strong: No wobbling or vibrations - strength-tested to bear a weight of up to 63 stone (400kg)
- Durable: Installed 60 million times over the past 50 years, Geberit concealed cisterns represent the ultimate tried-and-tested solution
- Hygiene: No pedestal and no cistern in front of the wall means no exposed pipework for dirt and bacteria to hide
- Simple Maintenance: Simply remove the flush plate for access to all important parts. Geberit stock spare parts for 25 years
- Tested Impermeability: Every Geberit cistern is individually tested to guarantee water tightness
- Acoustics Solutions : Acoustic solutions with the Duofix frame mean it's all quiet behind the scenes
- For drywall construction
- For installation in part-height prewall installations
- For wall-hung WCs with connection dimensions in accordance with EN 33:2011
- For wall-hung WCs with projection up to 620mm
- For floor constructions 0-200mm
- Self-supporting frame, powder-coated
- Frame with 9mm drilling holes for fastening in wood frame construction
- Feet adjustable 0-200mm
- Foot plates made of plastic
- Foot plate depth suitable for installation in U-profiles UW 50
- Connection bend can be mounted without tools
- Concealed cistern with front actuation
- Concealed cistern, fully insulated against condensation
- Cistern fulfils standard requirements in accordance with EN 14055, Class II
- Immediate post flush possible with factory setting
- Water supply connection on the rear or top centre
- With conduit pipe for feed pipe for connection of Geberit AquaClean shower toilets
- Fastening option for electrical connection
- Supplied with a 10 year guarantee and 25 year on the spares from the manufacturer
