Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm
Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm
Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm
Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm
Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm
Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm
Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm
Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm
Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm
Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm
Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm
Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm
Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm

Villeroy & Boch Architectura MetalRim White Square Shower Tray 900mm x 900mm

Quick Code: 2848262
Ref: VBUDA9090ARA115V01P
Villeroy & Boch
£389.95 Inc. VAT

Special offer - available at a new lower price for a limited time

Was: £

PayPal Credit
Spread the cost with 12 monthly payments of £32.50 at 0% APR using PayPal.

Special Order

Usually delivered in around 20 days.

Free Delivery Available

Delivery postcode restrictions apply

Check

Villeroy & Boch Architectura MetalRim White Alpin Square Shower Tray - 900mm x 900mm

The ultra-flat Architectura shower tray takes minimalism and accessibility to the next level. At just 15mm high, this next generation rectangular tray boasts MetalRim technology, where the tray is reinforced by a galvanised steel profile along each edge. The surface is constructed of 4mm sanitary grade acrylic, giving a smooth and glossy feel much like a traditional tray. Includes a discreet, colour-matched waste cover (waste and trap body sold separately).

Product Features

  • Ultra-flat, rimless square shower tray measuring 900mm x 900mm
  • Includes discreet, flush-fitting, colour-matched waste cover (waste body not included)
  • Just 15mm high - best suited to create a level-access showering area
  • The core of the tray consists of a high-strength, water-resistant composite material
  • MetalRim technology - all 4 sides of the tray are reinforced by a galvanised steel profile
  • 4mm sanitary grade cast acrylic surface layer - non-porous, hygienic and UV-resistant
  • Incredibly strong - stability tested to a maximum load bearing capacity of 1000kg
  • Impressive flow rates of over 50 litres per minute are achievable
  • 3 potential installation methods: level access, surface mounted or raised height
  • Supplied with a 10 year guarantee from Villeroy & Boch

Important Information

  • Colour-matching waste cover included - waste/trap body sold separately
  • An adjustable leg set is available separately for raised height installations
Show More

Shower Tray TypeStandard
ShapeSquare
Tray Size900mm x 900mm
Tray Height15mm
Waste PositionSide
Shower Waste Included?No
Waste Grate/Cover Included?Yes
Outlet Connection Size90mm
Core MaterialSteel-Reinforced Composite
Surface Material4mm Cast Acrylic
Surface TextureSmooth (Anti-Slip Class A)
Installation TypesLevel Access, Floor Mounted, Raised Height
ColourWhite Alpin
BrandVilleroy & Boch
CollectionArchitectura
Weight11.00 kg
Manufacturer Part NumberUDA9090ARA115V-01
